7mm Heat Set STS-HSR Rope

Home » Cordage » 12 Strand Rope » Uhmwpe Hmpe » 7mm Heat Set STS-HSR Rope

Rating | Write a Review | Read all Review (0) |

Product Description:

ROPE HMPE STS-HSR NE ROPE 7mm

12 STRAND TEUFELBERGER ROPE

Price per Foot

Item #

SKU:
48SPHS-HS12S09
Price (ea.) $6.15
Brand
Stage Brand
Mfg. Model #
C1628-07-00660
Ship Weight (lbs.)
0.025 lb
Availability Available in stock

Tech Specs

7mm (5/16 inch) HSR-STS Heat Set Rope

The rope made of HMPE (high modulus polyethylene) fibers is heat-treated, under tension, at temperatures greater than 100 deg C / 212 deg F. At a microscopic level, this process causes the molecular chains to be oriented such that they are linear, thus ensuring greater load bearing capacity. The STS process under exposure to heat increases the rope's breaking strength by achieving a uniform distribution of the HMPE fi ber lengths throughout the rope's longitudinal profile.

Features

Higher Breaking Strength at same Diameter (Up to 28% more breaking strength at equal diameters)
Same breaking strength at smaller diameter and less weight
Low Constructional Elongation
Longer Service Life due to closed rope structure, even with a cover
Stable Rope Cross-Section

The STS Technology

The rope made of HMPE (high modulus polyethylene) fibers is heat-treated,under tension, at temperatures greater than 100 deg C / 212 deg F.
At a microscopic level, this process causes the molecular chains to be oriented such that they are linear, thus ensuring greater load bearing capacity.
The STS process under exposure to heat increases the rope's breaking strength by achieving a uniform distribution of the HMPE fiber lengths throughout the rope's longitudinal profile.

Advantages Of A Rope With STS Technology

Higher breaking strength at same diameter
Same breaking strength at smaller diameter and less weight
Low constructional elongation
Longer service life due to closed rope structure, even without cover

Advantages Of The STS Technology

TEUFELBERGER STS ropes are constructed using a precisely controlled process which utilizes the ideal balance of temperature and tensioning thanks to:

Uniform tension
Uniform heating
Minimized rotation of the rope during the process
Uniform fiber lengths

in the rope's longitudinal profile

Molecular chains are oriented in the direction of the force
Improved degree of utilization of the fibers contained in the rope
Higher breaking strength
Stable rope cross-section
Closed rope structure

A minimum of 90% less constructional elongation

Fibre: HMPE (high modulus polyethylene) fibers

Water Absorption: 0%

Wet-dry Strength Ratio: 100%

Minimum breaking strength 18,700 pounds
